3BSE018405R1 TC513AF100 | IC200GBI001 | 數字信號|
3BSE018405R1 TC513AF100調制解調器是是一種能夠?qū)崿F(xiàn)通信所需的調制和解調功能的電子設備。
一般由調制器和解調器組成。在發送端，將計算機串行口產生的數字信號調制成可以通過電話線傳輸?shù)哪M信號；在接收端，調制解調器把輸入計算機的模擬信號轉換成相應的數字信號，送入計算機接口。
在個人計算機中，調制解調器常被用來與別的計算機交換數據和程序，以及訪問聯機信息服務程序等
3BSE018405R1 TC513AF100調制就是用基帶脈沖對載波波形某個參數進行控制，形成適合于線路傳送的信號。
解調就是當已調制信號到達接收端時，將經過調制器變換過的模擬信號去掉載波恢復成原來的基帶數字信號。采用調制解調器也可以把音頻信號轉換成較高頻率的信號和把較高頻率的信號轉換成音頻信號。
所以調制的另一目的是便于線路復用，以便提高線路利用率。
基于載波信號的三個主要參數，可以把調制方式分為三種：調幅、調頻和調相。分類方法播報編輯外置式Modem外置式Modem放置于機箱外，通過串行通訊口與主機連接。
這種Modem方便靈巧、易于安裝，閃爍的指示燈便于監視Modem的工作狀況。但外置式Modem需要使用額外的電源與電纜。
內置式Modem內置式調制解調器(5張)內置式Modem在安裝時需要拆開機箱，并且要對終端和COM口進行設置，安裝較為繁瑣。
這種Modem要占用主板上的擴展槽，但無需額外的電源與電纜，且價格比外置式Modem要便宜一些。
The 3BSE018405R1 TC513AF100 modem is an electronic device capable of achieving the modulation and demodulation functions required for communication.
It is generally composed of a modulator and a demodulator. At the sending end,
the digital signal generated by the serial port of the computer is modulated into an analog signal that can be transmitted through the telephone line.
At the receiving end, the modem converts the analog signal input to the computer into the corresponding digital signal and sends it to the computer interface.
In personal computers, modems are often used to exchange data and programs with other computers, and to access online information service programs
3BSE018405R1 TC513AF100 modulation is to use baseband pulse to control a certain parameter of the carrier waveform to form a signal suitable for line transmission.
Demodulation is when the modulated signal reaches the receiving end, the analog signal transformed by the modulator is restored to the original baseband digital signal by removing the carrier.
The use of modems can also convert audio signals into higher frequency signals and convert higher frequency signals into audio signals. Therefore, another purpose of modulation is to facilitate line multiplexing in order to improve line utilization.
Based on the three main parameters of the carrier signal, the modulation mode can be divided into three types: amplitude modulation,
frequency modulation and phase modulation.
Category Method Broadcast Editing External Modem The external Modem is placed outside the chassis and connected to the host through a serial communication port.
The Modem is convenient and easy to install. The blinking indicator helps to monitor the working status of the Modem. However,
an external Modem requires additional power supplies and cables. Internal Modem Internal Modem (5 pieces) The internal modem needs to be removed from the chassis and set the terminal and COM port,
which is complicated to install. This Modem occupies the expansion slot on the motherboard, but does not require additional power supplies and cables, and the price is cheaper than an external Modem.
