>>>>>型號:5SHY4045L0006 IGCT模塊 IGCT集成門極換流晶閘管
【功能描述】
一般信息
產品編號：3BHB030310R0001
ABB型號名稱：4500V，91mm，5SHY 4045L0006
目錄說明：4500V，91mm，5SHY 4045L0006;IGCT模塊
詳細描述：4500V，91mm，5SHY 4045L0006
IGCT集成門極換流晶閘管(Intergrated Gate Commutated Thyristors)是一種中壓變頻器開發的用于巨型電力電子成套裝置中的電力半導體開關器件(集成門極換流晶閘管=門極換流晶閘管+門極單元)。
1997年由ABB公司提出。IGCT使變流裝置在功率、可靠性、開關速度、效率、成本、重量和體積等方面都取得了巨大進展，給電力電子成套裝置帶來了新的飛躍。
IGCT是將GTO芯片與反并聯二極管和門極驅動電路集成在一起，再與其門極驅動器在外圍以低電感方式連接，結合了晶體管的穩定關斷能力和晶閘管低通態損耗的優點，
在導通階段發揮晶閘管的性能，關斷階段呈現晶體管的特性。IGCT 具有電流大、阻斷電壓高、開關頻率高、可靠性高、結構緊湊、低導通損耗等特點，而且造成本低，成品率高，有很好的應用前景。
>>>>>型號:5SHY4045L0006 IGCT模塊 IGCT集成門極換流晶閘管
【英文介紹】
General information
Product number: 3BHB030310R0001
ABB model name: 4500V, 91mm, 5SHY 4045L0006
Description: 4500V, 91mm, 5SHY 4045L0006; IGCT module
Detailed description: 4500V, 91mm, 5SHY 4045L0006
IGCT Intergrated Gate Commutated Thyristors (IGCT integrated gate commutated thyristors = gate commutated thyristors + gate units) is a type of power semiconductor switching device developed by a medium voltage inverter for use in large power electronics packages.
It was proposed by ABB in 1997. IGCT has made great progress in power, reliability, switching speed, efficiency, cost, weight and volume, and has brought a new leap to power electronic complete sets.
IGCT integrates the GTO chip with the anti-parallel diode and gate driver circuit, and then connects it with the gate driver in a low inductance mode at the periphery, combining the stable turn-off ability of the transistor and the advantages of the low on-state loss of the thyristor.
The performance of thyristor is displayed in the on-stage, and the characteristics of transistor are displayed in the off-stage. IGCT has the characteristics of large current, high blocking voltage, high switching frequency, high reliability, compact structure, low on-off loss and so on, and has a good application prospect.
