>>>>>型號:FBM233 現場設備系統集成模塊 雙端口以太網設備
【功能描述】
每個FBM233模塊具有單個10/100Mbps銅以太網連接和一個RJ-45模塊前面的連接器用于連接到雙端口以太網設備。FBM233是連接到以太網交換機或集線器，以便與一個或最多64個外部設備通信外部設備。
一對模塊組合在一起提供冗余現場總線模塊(FBM)級別。在這個配置中，一臺FBM233是Master，另一臺是跟蹤模塊?？刂普旧系妮斎朦c是否從設備上接收到的輸入更新連接到Master的網絡。設備輸出點(取決于I/O驅動程序)由Master和Tracker模塊。角色轉換如果檢測到問題(例如，I/O驅動程序導致的任何設備的心跳丟失;或者用戶可以隨時切換角色SMDH。顯示一般網絡配置圖1所示。
配置器
FDSI配置器設置FBM233端口和基于XML的設備配置文件。港口配置器允許容易地設置每個端口的通信參數(例如，動態主機配置協議IP地址)。不需要設備配置器對于所有設備，但當需要時，它配置設備具體和點具體的考慮(例如，掃描速率，要傳輸的數據的地址，和一次要傳輸的數據量事務)。
操作
每對FBM233最多可以接入64臺設備來讀寫數據。
>>>>>型號:FBM233 現場設備系統集成模塊 雙端口以太網設備
【英文介紹】
Each FBM233 module has a single 10/100Mbps copper Ethernet connection and an RJ-45 module front connector for connecting to dual-port Ethernet devices. The FBM233 is connected to an Ethernet switch or hub in order to communicate with one or up to 64 external devices.
A pair of modules are combined to provide a redundant fieldbus module (FBM) level. In this configuration, one FBM233 is the Master and the other is the tracking module. Whether the input point on the control station updates the network connected to the Master from the input received on the device. Device output points (depending on the I/O driver) are made up of Master and Tracker modules. If a problem is detected (for example, I/O drivers cause any device to lose its heartbeat; Alternatively, you can change the SMDH role at any time. The general network configuration shown in Figure 1 is displayed.
allocator
The FDSI configurator sets up the FBM233 port and the XML-based device profile. The port configurator allows you to easily set communication parameters for each port (for example, dynamic host Configuration Protocol IP address). Device configurator is not required for all devices, but when required, it configure-specific and point-specific considerations (e.g., scan rate, address of data to be transferred, and amount of data to be transferred at a time).
Controls
A pair of FBM233 can access a maximum of 64 devices to read and write data.
